Sunine K720/K730/K750 K Series Fiber Laser Marking Machines

QR code
what's fiber laser?
fiber laser is a laser in which the active gain medium is an
optical fiber doped with rare-earth elements. Fiber laser are compact compared with solid-state or gas lasers of comparable power, because the fiber can be bent and coiled, except in the case of thicker rod-type designs, to save space. They have lower cost of ownership. Fiber lasers are reliable and exhibit high temperature and vibrational stability and extended life time
Type FIBER
Brand SUNINE
Model K720
Power 20W
Weight 31KG
Wavelength 1064nm
Operation System Linux
Laser Type fiber laser source
marking field Standard 110mmX110mm maximum optional: 600mmX600mm
Consult immediately
DetailSpecificationsApplications


 Easy to use:

Sunine flexible and user-friendly laser controller simplified laser marking \management for users. It allows customers

to create store and execute jobs locally, eliminating the need for local computer control. For customers, this translates

flexibility for equipment location,increased productivity,

and lower PC costs.




 Designed for high production efficiency:

The features of the marking speed of 18000mm/s,remote

access, control, and monitoring enable customers to improve

productivity. The local exe-cution and streaming modes

of Sunine new V5marking software fits customer automation requirements.





 Compact design:

The compact design, based on a cast aluminum structure,and high-quality optical components guarantee strength and low maintenance.Whether integrated in a production lines orrobotic cell, the laser implementation is easy inall mounting positions. The 360-degree rotatablelaser head

can be oriented to the part surface to significantly reduceinstallation times and toolingcosts.


 Along lifespan:

Fiber laser is developed for a lifetime of nearly100,000

hours in demanding environmentswhere uptime is critical.

They are the most reliablelow-noise lasers in the market. Alignment-free and maintenance-free.










Model

K720

K730

K750

Power

20W

30W

5W

Case materials

Anodized Aluminum (Laser Head) & Stainless Steel (Control Unit)

Laser type

Fiber laser source

Laser wavelength

1064m

Marking method

High-precision 2D scanning

Marking speed

≤12000mm/s

Main control

Highly-integrated motherboard with 10 inch touch screen controller, V5 operation system

Cooling method

Air-cooled

Operation system

Linux

Type of marking

Both Dot martix & vector

Reflector size

Standard: 8.5mm

Marking filed

Standard: 110mmX110mm maximum optional:600mmX600mm

Positioning method

Red light positioning, auto focus

Number of lines

No limits within marking filed

Production line speed

0-189/min(varies according to materials and printing contents)

Language

English, Chinese, Spanish, Russian, Korean, Arabian etc.

File format

BMP/DXF/HPGLIJPEG/PLT

Bar code /QR code

CODE39/CODE128/code126/QRcode/Z-code/DM codeNisual code.etc

Power supply

220V/110V

Max cosumption

≤400W

600W

Weight


Laser head size

458mmX111mmX83mm

Control unit size

492mmX383mmX160mm

Interfaces

RS-232C/USB2 0/Ethernet.l/O

Casing protection level

IP54(laser head, IP65 is an option )

Pollution level

2

Type of overvoltage

II

Working condition

5 to 40℃; ≤85RH(No-condensing)




Virtually every common metal (and a number of uncommon ones) can be marked with 1064nm laser marking system. Precious metals, stainless and hardened steel, copper and anodized aluminum all mark extremely well. It can also mark on non-metal materials such as aluminum foil, PVC, etc. It’s widely used in industries of food, pipes, wires & cables, pharmaceutical, etc.

fiber_sample_metal (26).JPGfiber_sample_metal (12).JPGfiber_sample_metal (20).JPGlaser marking on stainless steel.jpg二维码.jpg
